HYBIRD INVERTER SC-MAX11KW

Model: Hybrid Inverter SC-MAX11KW

Design: Sleek black and white design with customizable RGB status light bar

Operating Temperature: -10°C to +50°C

Key Technical Specifications

Inverter Mode

1. Power: 11000VA / 11000W (Surge Power: 22000VA)
2. DC Input: 48VDC – 250A
3. AC Output: 230VAC – 50/60Hz – 47.8A | Single Phase (1Φ)

AC Charger Mode

1. Input: 230VAC – 50/60Hz – 60A
2. DC Output: 54VDC (Max 150A – Adjustable)
3. AC Output: 230VAC – 50/60Hz – 47.8A | Single Phase (1Φ)

Solar Charger Mode (Dual MPPT)

1. Total PV Power: 11000W (5500W × 2)
2. Nominal Voltage: 240VDC – 360VDC
3. Maximum Solar Voltage (VOC): 500VDC
4. MPPT Range: 90VDC to 450VDC
5. Max Solar Charge Current: 150A

Additional Features

Protection Rating: IP21

Connectivity: Built-in Wi-Fi mobile monitoring (iOS/Android) & BMS port (RS485/CAN)

Parallel Capability: Supports parallel operation up to 6 units (Single or 3-Phase)

Compliance: RoHS and CE compliant

Made in China

Why Choose This Inverter?

Ultra-High Capacity: Power heavy inductive loads and entire households up to 11kW smoothly.

Dual MPPT Tracking: Maximize solar collection with two independent PV inputs.

Battery-Independent Operation: Can power loads directly from solar without batteries connected during the day.

Smart RGB Lighting: Quick visual identification of system status (Solar, Grid, Battery).

Flexible Expansion: Easy to scale capacity in the future up to 66kW.
